EV AC Charger

Commercial Charging

    Optional Connector Type
    J1772 (Type1) and Type2 connector and cable provided; support for all new EV models.

    Screen Display
    Equipped with LCM screen to clearly display charging information.

    Delay Charge
    Free to set 1/2/4/8hr automatic delay charging, choose cheap electricity price.

    Color Light Bar
    Convenient for car owners to know the charging state from a distance.

    Winding Groove Design
    Stored the charging gun and wiring neatly for your convenience.

    Maintenance Hole Design
    No need to dismantle the whole machine for maintenance.

    Emergency Button
    Stop charging at any time according to special circumstances.

    High Standard Safety Protection
    When abnormal condition is detected, power will be cut off automatically.

    • Car Parks

    • Residential Area

    • Restaurants and Hotels

    • Office Buildings

    • Tourist Attractions

    Category Item CBDA-X50A CBDA-X80A CBDA-X32B CBDA-X70B
    Input Voltage Range AC 220 ±10% AC 220 ±10% AC 220 ±10% AC 220 ±10%
    Frequency Range Single phase 60Hz Single phase 60Hz Single phase 60Hz Single phase 60Hz
    Input Current 50A 80A 32A 70A
    Input Power Connect L, N, GROUND L, N, GROUND L, N, GROUND L, N, GROUND
    Output Voltage Range AC 220 ±10% AC 220 ±10% AC 220 ±10% AC 220 ±10%
    Frequency Range 60Hz 60Hz 60Hz 60Hz
    Output Current 50A 80A 32A 70A
    Output Power 11kW 17.6kW 7.04kW 15.4kW
    Physical Specification Connector Type SAE J1772 (Type1),  Type2
    Cable Length 17 FT (5.1M)
    Enclosure Dimension (H*W*D) H 393.9 * W 338.7 * D 144.4 mm (excluding stand)
    Weight 8.6 KG
    User Interface Buttons Multi-function, Emergency, Delay, Info Buttons
    Indicator Light Standby: Green, Charging: Blue, Complete: Flashing Green, Fault: Red
    User Identification RFID (MIFARE CARD)
    LCM Screen English
    Protection Protection Features Over-voltage, Over-current, Short-circuit, Leakage, Overload, Surge protection
    Environmental Operating Temperature -25°C to +50°C
    IP IP 55
    Humidity <95%
    Standard Compliance Standard CNS15511
    Communications Wi-Fi / RJ45 Ethernet
